Specifications Attribute Value Type Sleeve Type Load (Lbs) @80 PSI688Load (Lbs) @100 PSI860Design Height (In)5.20Top Plate Hole/Stud Qty1Top Plate Dia. (A)2.99Top Plate C to C Dia. (B)N/ABottom Plate Hole/Stud Qty1Bottom Plate Dia. (C)2.91Bottom Plate C to C Dia. (D)2.25BumperNoMin. Height2.20Max. Height8.50Max. Dia.4.40Applications Make Series Additional InformationPeterbilt388 (No Year)Peterbilt389 (No Year)Cross Reference Name Number Notes FirestoneW02-703-7163Air Spring CabinFirestoneW023587155Air Spring CabinFirestoneW02-358-7155Air Spring CabinFirestoneW027037163Air Spring CabinFirestoneW027037165Air Spring CabinFirestoneW02-703-7153Air Spring CabinFirestoneW027037164Air Spring CabinPeterbiltR816002Air Spring CabinFirestoneW02-703-7164Air Spring Cabin
