Specifications
| Attribute | Value |
|---|---|
| Type | Rolling Lobe |
| Automann Bellows# | 1DK28M |
| Firestone Bellows# | 1T19LF-7 |
| Goodyear Bellows# | 566-28-3-042 |
| Contitech Bellows# | 11 10.5F-17.5 |
| Load (Lbs) @80 PSI | 9100 |
| Load (Lbs) @100 PSI | 11400 |
| Natural Freq. (CPM) | 81 |
| Design Height (In) | 10.00 |
| Bottom Plate Type | Plastic |
| Top Plate Hole/Stud Qty | 2 |
| Top Plate Dia. (A) | 11.31 |
| Top Plate C to C Dia. (B) | 5.50 |
| Bottom Plate Hole/Stud Qty | 1 |
| Bottom Plate Dia. (C) | 10.16 |
| Bottom Plate C to C Dia. (D) | N/A |
| Bottom Part # | BS10179 |
| Bumper | Yes |
| Bracket | N/A |
| Min. Height | 5.10 |
| Max. Dia. | 15.40 |
Cross Reference
| Name | Part Number | Notes |
|---|---|---|
| Contitech | 11 10.5F-17 P 745 | Air Spring Rolling Lobe |
| Contitech | 65593 | Air Spring Rolling Lobe |
| Firestone | 8774 | Air Spring Rolling Lobe |
| Firestone | W013588774 | Air Spring Rolling Lobe |
| Firestone | W01-358-8774 | Air Spring Rolling Lobe |
| Goodyear | 1R14172 | Air Spring Rolling Lobe |
| Goodyear | 1R14-172 | Air Spring Rolling Lobe |
| Goodyear | 1R14190 | Air Spring Rolling Lobe |
| Goodyear | 1R14-190 | Air Spring Rolling Lobe |
| Hendrickson | S25873 | Air Spring Rolling Lobe |
| Hendrickson | S-25873 | Air Spring Rolling Lobe |
| Hendrickson | S27341 | Air Spring Rolling Lobe |
| Hendrickson | S-27341 | Air Spring Rolling Lobe |
| Watson&Chalin | AS0159 | Air Spring Rolling Lobe |
| Watson&Chalin | AS-0159 | Air Spring Rolling Lobe |
| Watson&Chalin | AS-0159-1G | Air Spring Rolling Lobe |
| Watson&Chalin | AS0159G | Air Spring Rolling Lobe |
| Watson&Chalin | AS-0159G | Air Spring Rolling Lobe |
