Specifications Attribute Value Type Sleeve Type Load (Lbs) @80 PSI840Load (Lbs) @100 PSI1050Natural Freq. (CPM)95Design Height (In)5.25Top Plate Hole/Stud Qty1Top Plate Dia. (A)3.15Top Plate C to C Dia. (B)N/ABottom Plate Hole/Stud Qty1Bottom Plate Dia. (C)2.87BumperNoMin. Height4.50Max. Height10.00Max. Dia.5.10Where UsedThis item is not featured in any schematics.Applications Make Series Additional Information Freightliner Argosy (No Year)FreightlinerCentury (No Year)FreightlinerColumbia (No Year)FreightlinerFLD120 (No Year)FreightlinerM2 106 (No Year)FreightlinerM2 Business Class (No Year)Cross Reference Name Number Notes Contitech67452Air Spring CabinContitechSC31-W206Air Spring CabinFirestonePS19371Air Spring CabinFirestone7202Air Spring CabinFirestone7206Air Spring CabinFirestoneW02-358-7202Air Spring CabinFirestoneW02-377-7206Air Spring CabinFirestoneW023587202Air Spring CabinFirestoneW023587206Air Spring CabinFirestoneW023777206Air Spring CabinFreightliner18-29919-000Air Spring CabinFreightliner1829919000Air Spring CabinGoodyear1S5-176Air Spring CabinGoodyear1S5176Air Spring CabinLink1102A047Air Spring CabinTorqueTR7206Air Spring Cabin
